6 GPM Billet Belt Drive Mechanical Fuel Pump (See P/N 17140 or 17241 for pump with mounting bracket, pulleys and hardware.).
Zero amperage draw, less weight, and more flow! The Aeromotive Billet Belt Drive Fuel Pump was designed to solve fuel delivery problems in high horsepower, forced-induction EFI applications, as well as the now popular carbureted applications on gas or methanol.
Zero amperage draw, less weight, and more flow! The Aeromotive Billet Belt Drive Fuel Pump was designed to solve fuel delivery problems in high horsepower, forced-induction EFI applications, as well as the now popular carbureted applications on gas or methanol.
- Proven performance, powering some of the world's fastest EFI vehicles
- Supports up to 3600 HP gas and 1800 HP methanol
- Compact size facilitates easy mounting
- Billet aluminum CNC-machined body, not 'cast'
- ORB-10 inlet and outlet ports
- Bracket and Cog Pulley sold separately
Information:
supports up to 3600 HP gas; supports up to 1800 HP methanol; compact size facilitates easy mounting| Attributes | |
| ASIN | B000F0QA7C |
| Attributed Description | Aeromotive Fuel System; Mechanical Fuel Pump; Housing Material: billet aluminum; New Or Remanufactured: New; Inlet Diameter: ORB-10; Outlet Diameter: ORB-10 |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Country of Origin (Primary) | US |
| EFI HP on E85 | 2800, 2800 |
| EFI HP on Gas | 4000, 4000 |
| Emission Code | Off Road |
| Harmonized Tariff Code (Schedule B) | 8413300000 |
| Hazardous Material Code | N |
| HOUSING MATERIAL | billet aluminum |
| Inlet Diameter | 0.625, 0.625 |
| Inlet Outside Diameter | ORB -10, ORB -10 |
| Life Cycle Status Code | Available to Order |
| Maximum Pressure | 60, 60 |
| Mounting Type | External, External |
| NAFTA Preference Criterion Code | B |
| New Or Remanufactured | New |
| Outlet Diameter | 0.625, 0.625 |
| Outlet Outside Diameter | ORB -10, ORB -10 |
| SDR Required Flag | N |
| Warranty Time | 12 |
| GTIN | 00684980000832 |
