Doug's Long Tube Header 66-69 Ford 390-428 FE Motor Automatic Trans 1 3/4" Primary 3" Collector Black Hi Temp Coated D625-B
Long tube headers provide the greatest increases in horsepower and torque across the entire RPM spectrum. The choice of racers worldwide, Doug's long tube headers are designed for the car owner who wants maximum power and the highest quality header on the market.
- 3/8" Thick machined flanges to prevent warping
- Precision formed long transition collectors and long tube design reduces backpressure and increases higher RPM horsepower
- Heavy duty 16-gauge tubing for long life
- Tubes are pre-polished to removed scratches before applying metallic ceramic or hi-temp black coating
Information:
For the enthusiast who demands the best, Doug's Headers are not just components; they're a statement of excellence, a commitment to leading-edge performance, and a nod to the glory days of muscle cars and drag racing. Join the ranks of champions. Experience the unmatched quality and performance of Doug's Headers today.
Application Summary:
| Year |
Make/Model |
| 1966-1969 |
Ford Fairlane |
| 1967-1969 |
Ford Ranchero |
| 1968-1969 |
Ford Torino |
| 1966-1969 |
Mercury Comet |
| 1968-1969 |
Mercury Montego |
| Attributes |
| ASIN |
B00KKSX1KI |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Collector Attachment |
3-Bolt Flange |
| Collector Diameter |
3.000 in., 3.00 |
| Collector Port Diameter |
3.0 |
| Color |
Black, Black |
| Country of Origin (Primary) |
MX |
| Cylinder Head Port Shape |
Rectangular |
| Design |
Full-length |
| EmissionFullDES |
4 - This Product is considered a Replacement Part per CARB and EPA regulations for emissions compliance and is legal for sale and use on specified vehicles in all 50 states as stated in Manufacturer’s Application Guide and Installation Instructions., 4 - This Product is considered a Replacement Part per CARB and EPA regulations for emissions compliance and is legal for sale and use on specified vehicles in all 50 states as stated in Manufacturer’s Application Guide and Installation Instructions. |
| Finish |
Hi-Temp Black Coating, Hi-Temp Black Coating |
| Flange Thickness |
0.375, 0.375 |
| Flange Thickness (in) |
3/8 in. |
| Gasket Or Seal Included |
Yes |
| Gaskets Included |
Yes, Yes |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Header Finish |
Black, Hi-Temp Black Coating |
| Header Material |
Steel, Steel |
| Header Style |
Full-length, Full-length |
| Life Cycle Status Code |
Available to Order |
| Material |
Steel |
| Mounting Hardware Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| Oxygen Sensor Port |
No |
| Port Shape |
Rectangular |
| Primary Tube Outside Diameter |
1.75, 1.75 |
| Primary Tube Outside Diameter (in) |
1 3/4 in. |
| SDR Required Flag |
N |
| Sheen Level |
Matte |
| Tube Wall Thickness |
16 |
| Warranty Time |
12 |
| GTIN |
00694342543594 |
